Rugged Mobile Device with Two Functions of Thermal Printer and
Fingerprint Reader
Advantages of K50 Rugged Mobile Device:
- Android 5.1
- 4G LTE
- 1GB RAM or 2GB RAM Custom Made
- 5.0inch High-definition IPS LCD capacitive touch screen
- IP65 Industrial Class, 1.5M drop protection
- Special Structure and External Cushion Protection Design
- Matched with the machine seat charger
- OEM/ODM Accepted
- Support 1D/2D Barcode Scanning, LF/HF/UHF RFID/fingerprint reading, terminal printer, MSR, PSAM
function etc.
- Multiple Functions Optional: card reader, printer, fingerprint,
infrared reader, temperature, etc
Thermal Printer: 2 inch Direct thermal line printing
Fingerprint reader: Crossmatch TCS1 (meet the FBI’s FIPS-201)
Paraments of Rugged Mobile Device:
OS | Android 5.1 |
| Core | CPU | Quad-core 1.3GHz ARM® Cortex-A53 |
| WWLAN | FDD B1B3B7
TDD B38B39B40
WCDMA B1B2B5B8
EVDO BC0
GSM B2B3B5B8 |
| Flash ROM | 16GB |
| RAM | 2GB DDR3 |
General Configuration
| Display | Main Screen | 5.0 inch IPS 1280*720 |
| Touch screen | Multi-point touch capacitive screen |
| GPS | Support GPS/QZSS/SBAS (WAAS/MSAS/EGNOS/GAGAN). Support Full AGPS |
| Bluetooth | v2.1+EDR / 3.0+HS / v4.0 Low Energy (LE) |
| WiFi | 802.11 a/b/g/n |
| Protection class | IP65 |
| Drop resistance level | 1.5m |
| Camera (OPTION) | Rear camera | 8MP Camera |
| Keypad | Front /Side | 4/4 |
| Interface | Micro-USB connector | USB2.0 Connection |
| SIM card slot | *2 |
| TF card slot | Yes |
| power jack | Micro-USB |
| Audio Jack | Yes |
| Battery | Type | 2600mAh 19.24WH |
| Standby Time | 500hours |
| Calls Time | Up to 6 hours |
| Charging Time | 4 hours (USB charging) |
| Physical Characteristics | Dimension | 175*76*27mm |
| Weight | >400g with battery (according config) |
FAQ:
Question 1: what's your MOQ?
Answer: the MOQ of speedata barcode scanner handheld PDA is 1 unit.
Question 2: how long is the delivery time?
Answer: The delivery time of barcode scanner goods is different
from quantities:
If 1~100 pcs, It's about 5--10 working days;
If 100~500 pcs, it's about 10--20 working days;
If More than 500 pcs, It's about 20-30 working days.
Question 3: Would you like to supply 1 sample for testing?
Answer: Yes, Of course. We can provide 1 sample Terminal PDA for your testing.
Question 4: What's the total price for 1 sample?
Answer: As a manufacturer of barcode scanner terminal PDA.the more
you buy,the cheaper it'll be.
the sample price is a little bit higher than the common wholesale price.excluding the freight fee. |
Question 5: Are you a manufacturer of Handheld PDA?
| Answer: Yes, we are a chinese listed company of R&D and producing industrial PDA
Terminal hardware and software solutions with over 8 years' OEM/ODM experience. and also we cooperate with Foxconn. |
Question 6: what kind of services do you support?
| Answer: 1.We provide you Free SDK and technical support for your barcode scanner.
2.we also provide ODM/OEM customization services according to your needs.
3.We support 13 months Warranty for your devices and other parts. and 6 months for the batteries.
Exend warranty,it costs 0.5% for each per year. |
Question 7: what's for payment term and delivery term ?
Answer:
1.It's generally 30%-100% TT in advance for all orders for the payment term.
with supporting via bank card, Paypal or West Union.
2. FOB Shenzhen for Delivery term.
IF you need more information and details, Please Feel free to
contact us. Thanks for your attention.
