Operating System

Android 5.1 OS

SDK

Software Development Kit

Language

C#, java

Tool

Microsoft Visual Studio 2005

CPU

ARM® Cortex-A7 MPCoreTM (LPDDR2 and LPDDR3) Quad-core 1.3Ghz

Memory

1GB DDR3 RAM + 8GB Frash ROM

Storage

Micro SD/TF card max.32GB expansion

WWLAN

FDD B1B3B7
TDD B38B39B40
WCDMA B1B2B5B8
EVDO BC0
GSM B2B3B5B8

WiFi

2.4Ghz 802.11 b/g/n

Bluetooth

V2.1+EDR / 3.0+HS / V4.0 Low Energy(LE)

GPS

Supports GPS/QZSS/SBAS (WAAS/MSAS/EGNOS/GAGAN).

Support Full AGPS

Dimensions

166 * 74 * 16mm (Thickest 30mm)

Weight

≧300g with battery (according config)

Display

4.5inch IPS 480 * 800 px with Multi-point touch capactive screen

Expansion Slots

1*Standard SIM apply GSM,GPRS,EDGE, 1*Micro SIM apply 3G

Battery

rechargeable li-ion battery 4200mAh 3.7V

500-hours standby time, Up to 6-hours calling time, 4-hours charging time

Camera

8MP Camera

Video

Support still image and video capture

Audio

3.5mm 4way plug

Keypad

Front 23keys, Side 4keys

Interfaces

1*MicroSD/TF, 1*Audio Jack, 1*Micro USB, 1*Power Jack

USB Host/RS-232 interface (Customized)

Operating Temp.

-10 to 50℃

Humidity

10%RH - 90%RH (Non-condensing)

Protection class

IP65

Drop resistance level

1.5M

RFID NFC

RFID NFC(Compatible 13.56MHz ISO 14443A/ ISO15693)

1D Laser scanner

Symbol SE955 (Optional 1)

1D/2D CMOS laser scanner

Newland EM3095 -hardware decoding (Optional 1)

Symbol SE4500 (Optional 2)
